MC100
  • Features:

    ·Support customer's secondary development and protect customer's core technology

    ·Rich communication interface

    ·Metal housing, plug-in signal connector

    ·Stable and reliable performance, long service life, high cost performance

    ·Strong anti-interference, stable and reliable collected signal

    ·Built-in power isolation and short circuit protection

    ·Can meet the needs of customers in various applications


  • Project Specifications
    Brand Porcheson
    Host model MC100
    Programming software PsMagic V3.28 (support user’s secondary development, language: ladder diagram +C language)
    Performance CPU: ARM, program scanning cycle:  than 1ms
    Input I 16channels wet contact (NPN),3 channels dry contact (relay), input power short circuit protection
    Output O 18channels wet contact (NPN),4 channels dry contact (relay)
    Communication interface RS232、RS485、CAN
    Working voltage Service voltage:DC18V~36V
    Environment Working temperature: -20℃~70℃; storage temperature: -40℃~85℃; relative humidity: 15%~85%
    Recommended type single/ two-armed manipulator,Gasdynamic
    Remarks Parameters of the product may be changed due to technical update or improvement without prior notice. All ordered products and parameters are subject to the physical product.


  • 1594431721656990.png

    • NameVersionFormatSizeDateDownload
    • Product manual
      No data
      Drive
      No data
      Application software
      No data
      Product certificate
      No data
      3D drawings
      No data
